SPECIFICATION
| Standard(s) | EN 60669-1 |
| Rating | 20 A(X), 250V~ |
| Switch Type | Double Pole |
| Contact Gap | Normal Gap |
| Terminal Capacity | 3x 2.5mm² ,2x 4.0mm²，1x 6.0mm² |
| Size | 116mm x 158mm x 90mm |
| Product Class 1 | Face plate does not need to be earthed |
| Ambient Operating Temperature | -5° to +40°C |
| IP Rating | IP66 |
LINE DIAGRAM
